USB C Docking Station Dual Monitor Review
Transform your chaotic workspace with our review of the USB C Docking Station Dual Monitor. Discover its 14-in-1 features for seamless connections. Read more!
Nearly identical to the ABIWAZY 14-in-1 we have already reviewed (B0D8HX861F), with the same port layout: dual HDMI, VGA, three USB 3.0, USB-C data, two USB 2.0, USB-C PD, Gigabit Ethernet, SD/TF, and 3.5mm audio. Same resolution cascade: HDMI 1 at 4K@60Hz single, 4K@30Hz + 1080p dual, 1080p triple with VGA. Same one-HDD limitation. Same macOS mirror-only behavior. The differences between the two ABIWAZY listings are minor: this one specifies 87W actual delivery to the laptop from 100W PD, adds iPhone 17/16/15 and Linux Mint 21 to the compatibility list, and carries a 1-year manufacturer warranty. If you are choosing between the two ABIWAZY 14-in-1 listings, the specs are functionally the same product under different ASINs.
Fourteen ports. Dual HDMI (4K@60Hz + 4K@30Hz). VGA (1080p). Three USB 3.0 (5 Gbps). One USB-C data (5 Gbps). Two USB 2.0. USB-C PD (87W to laptop from 100W). Gigabit Ethernet. SD/TF (104 Mbps, simultaneous). 3.5mm audio/mic. One HDD/SSD at a time. macOS mirror only. 6.5″ x 3.54″ x 0.71″. 1-year warranty.
Key Specifications
| Specification | Detail |
|---|---|
| Total Ports | 14 |
| HDMI 1 | 4K@60Hz (single use, DP 1.4 source) |
| HDMI 2 | 4K@30Hz (single use, DP 1.4 source) |
| Dual Display | 4K@30Hz + 1080p@60Hz (DP 1.4 source) |
| Triple Display with VGA | 1080p on all screens |
| VGA | 1080p |
| USB 3.0 | 3 (5 Gbps) |
| USB-C Data | 1 (5 Gbps) |
| USB 2.0 | 2 |
| USB-C PD | 87W to laptop (from 100W charger) |
| Gigabit Ethernet | 1 (10/100/1000 Mbps) |
| SD Card Reader | 1 (104 Mbps, simultaneous with TF) |
| TF/MicroSD Reader | 1 (104 Mbps, simultaneous with SD) |
| 3.5mm Audio/Mic | 1 (combo) |
| HDD/SSD Limit | Only 1 external drive at a time |
| macOS Display | Mirror only |
| Compatible OS | Windows 7/10/11, macOS, ChromeOS 137, Linux Mint 21 |
| Compatible Devices | iPhone 17/16/15, HP EliteBook/ProBook/ZBook/OMEN, Dell XPS/Latitude/Precision, Lenovo ThinkPad/Yoga, Surface Pro/Book/Go/Laptop, Huawei MateBook, Chromebook |
| Dimensions | 6.5″ L x 3.54″ W x 0.71″ H |
| Weight | Not specified |
| Manufacturer | ABIWAZY |
| Warranty | 1 year manufacturer |
USB C Docking Station Dual Monitor for Dell/HP/Lenovo/Surface Laptop, 14 in 1 Triple Display Hub Multiple Adapter, Dongle with 2 HDMI 4K+VGA+5 Port+100W PD Charger+Ethernet+SD/TF+Audio
87W to the Laptop: The PD Math
ABIWAZY specifies “up to 87W (Safety)” to the laptop from the 100W PD port. The dock reserves 13W for its own operations. MacBook Air (30-45W) and most Windows ultrabooks (45-65W) charge at full speed. MacBook Pro 14″ (70-96W) charges at near full speed. Laptops that draw 90-100W charge below their maximum rate. Use a 100W charger for maximum pass-through. A 65W charger through this dock delivers approximately 52W to the laptop.
Display Resolution Cascade
Single HDMI 1: 4K@60Hz. Plug your primary monitor here when using one screen.
Single HDMI 2: 4K@30Hz. Sharp but motion stutters compared to 60Hz.
Two HDMI displays: 4K@30Hz on one and 1080p@60Hz on the other. Bandwidth splits between the two.
Dual or triple with VGA: 1080p on all screens. VGA pulls everything down. For three 1080p monitors for email, Slack, and a browser, the setup works. For any workflow that needs 4K, keep VGA disconnected.
One External Drive at a Time
Only one HDD or SSD at a time despite having multiple USB ports. Connecting a second drive may cause disconnections or the drive not mounting. Keyboard, mouse, and one drive works. Two drives simultaneously does not.
macOS: Mirror Only
macOS shows the same content on all external monitors. No independent extend. No non-mirror mode like some competing hubs offer. For Mac independent multi-display, a DisplayLink dock handles that through software rendering.
iPhone 17/16/15 and Linux Mint 21
The compatibility list includes iPhone 17, 16, and 15 series — meaning USB-C iPhones can mirror to the HDMI display and charge through PD simultaneously. Linux Mint 21 and ChromeOS 137 are also listed, which broadens OS support beyond the typical Windows/macOS pairing. For Linux users who need a confirmed-compatible USB-C hub, this listing names a specific distribution and version.
Drawbacks
| Consideration | Detail |
|---|---|
| Near-Duplicate Product | Functionally identical to ABIWAZY B0D8HX861F under a different ASIN. |
| Triple Display: 1080p Only | No 4K when VGA is connected. |
| One HDD/SSD at a Time | Cannot connect multiple external drives. |
| macOS: Mirror Only | No independent extend on Mac. |
| 87W, Not 100W | Dock reserves 13W. Laptop receives 87W. |
| HDMI Ports Not Equal | HDMI 1 at 60Hz. HDMI 2 at 30Hz. |
| SD/TF at UHS-I | 104 Mbps. UHS-II cards bottlenecked. |
| Weight Not Specified | Dimensions listed but no weight. |
Who This Dock Is For
Windows laptop owners who need 14 ports with dual HDMI, VGA, Ethernet, five USB, card readers, audio, and 87W charging with a broad compatibility list including iPhone and Linux Mint: The ABIWAZY covers the standard 14-port formula with specified model compatibility across HP, Dell, Lenovo, Surface, and iPhone. 1-year warranty. If you already see the other ABIWAZY 14-in-1 (B0D8HX861F) and wonder how it differs, the answer is: it barely does. Same ports, same limitations, same brand. For the other ABIWAZY listing, see the ABIWAZY 14-in-1 Triple Display review.
Mac users who need independent extend, or buyers who need multiple drives or 4K on three screens: Mac gets mirror only. One drive at a time. Triple display is 1080p. For those needs, see the docking stations hub page.
Final Verdict
The ABIWAZY 14-in-1 (B09WDCH35N) provides the same fourteen-port formula as its sibling listing (B0D8HX861F) with minor additions: 87W actual delivery specified, iPhone 17/16/15 in the compatibility list, Linux Mint 21 support, and a 1-year warranty. The display cascade, one-drive limitation, and macOS mirror restriction are identical. For the Windows user who needs dual HDMI plus VGA, Ethernet, five USB, card readers, audio, and 87W charging from a hub with named model compatibility, the ABIWAZY delivers that. Plug your primary monitor into HDMI 1 for 60Hz, keep VGA disconnected when you need 4K, and do not connect two external drives at the same time.
Frequently Asked Questions
How is this different from the other ABIWAZY 14-in-1?
Same ports and same limitations. This listing specifies 87W actual delivery, adds iPhone 17/16/15 and Linux Mint 21 to compatibility, and includes a 1-year warranty. Functionally identical.
Which HDMI port should I use for my main monitor?
HDMI 1. It supports 4K@60Hz when used alone. HDMI 2 caps at 4K@30Hz.
Can I connect two external hard drives?
No. Only one HDD/SSD at a time despite having multiple USB ports.
Does it work with MacBook for extended displays?
macOS supports mirror mode only. All external monitors show the same content.
Disclosure: As an Amazon Associate, I earn from qualifying purchases.
Docking Station Intelligence
The standards are confusing by design. These three panels decode what manufacturers won’t explain clearly. Applicable to every docking station.
The USB-C Confusion Matrix
The USB-C connector is the single greatest source of buyer confusion in docking stations. The physical plug looks identical whether it carries USB 2.0 at 480 Mbps or Thunderbolt 5 at 120 Gbps — a 250x difference in capability hidden behind the same shape. Manufacturers exploit this by labeling everything "USB-C compatible" without specifying which protocol runs through it. Two docks can look identical on the outside and behave completely differently once you plug them in.
The hierarchy matters because it determines everything: how many monitors your dock can drive, how fast files transfer, whether your laptop charges while docked, and whether you need third-party drivers. Here is the real capability ladder, from slowest to fastest:
The practical takeaway: if your laptop has Thunderbolt 4, buy a Thunderbolt dock. If it only has generic USB-C, verify whether it supports DisplayPort Alt Mode before buying anything with multi-monitor claims. Our buying guide walks through verification steps for every major laptop brand.
Power Delivery: What the Watts Mean
Power Delivery (PD) determines whether your docking station can charge your laptop while you work, or whether you need a separate charger cluttering your desk. The math is simple but rarely explained: your laptop draws a specific wattage under load, and the dock must match or exceed it. If the dock delivers less than your laptop needs, the battery slowly drains even while plugged in — defeating the purpose of a docking station entirely.
Most ultrabooks need 45–65W. Standard business laptops need 65–100W. Gaming and workstation laptops can demand 100–140W or more. The dock’s advertised PD wattage is the maximum it can deliver to your laptop — but this drops if you charge other devices (phones, tablets) through the dock simultaneously. Always leave a 15–20W margin above your laptop’s requirement.
Check your laptop’s original charger wattage — that’s your baseline. Our FAQ covers how to find this for every major brand.
Native Display vs DisplayLink: The Hidden Factor
This is the decision most buyers don’t know they’re making. When a docking station outputs video to your monitors, it uses one of two fundamentally different methods: native (the dock passes your laptop’s GPU signal directly to the monitor) or DisplayLink (the dock compresses video over USB and a software driver renders it). The difference is invisible in marketing materials but profoundly affects your daily experience.
Native output through DisplayPort Alt Mode or Thunderbolt uses your laptop’s actual graphics hardware. There is zero added latency, full DRM support for streaming services, no CPU overhead, and no driver to install. DisplayLink, by contrast, adds 5–15ms of latency (noticeable in video calls and cursor movement), blocks DRM content on connected monitors (Netflix, Disney+ show black screens), consumes 3–8% of your CPU constantly, and requires a driver that Apple’s macOS security updates occasionally break.
DisplayLink exists for one reason: Apple Silicon base chips (M1, M2, M3) can only drive one external display natively. If you need two or more monitors on a base MacBook Air or 13” MacBook Pro, DisplayLink is your only option. For everyone else — Windows users, Mac Pro/Max chip users, Intel/AMD laptops — native is always the better choice.
Native (Alt Mode / Thunderbolt)
DisplayLink (USB compression)
The bottom line: if your laptop supports native multi-display output, always choose a native dock. DisplayLink is a workaround, not an upgrade. See our glossary for detailed definitions.
